Infomir MAG 254 IPTV BOX
Infomir MAG 254 IPTV BOX
Brand: Infomir
Rating : Product not rated yet ! - Add review now !
| Price per unit: 75,60 € | |
|---|---|
| Price ex VAT: 63,00 € | |
| Total price: Price is including 20% VAT ! |
75,60 € |
| Check Shipping price |
Set up Watch Dog for this item
Send demand to sales department
MAG 254/255 is a powerful set top box with STiH207 efficient processor and RAM memory increase, and it is an optimal solution for IPTV / OTT projects. The Set-Top Box is designed to Fulfill Business Projects of Internet Providers, OTT operators and content aggregators. The increased productivity of MAG 254/255 Enables to use resource-intensive applications and interactive 3D video support.
Specifications
Dimensions
| Width/depth/height, (mm): | 127/87/30 |
| Weight, g: | 190 |
Hardware
| Processor: | STiH207 |
| Flash memory: | 256 Mb |
Software
| Operating system: | Linux 2.6.23 |
| Built-in Media Portal with WebKit-based IPTV-functionality HTTP 1.1, HTML 4.01 XHTML 1.0/1.1; DOM 1, 2, 3, CSS 1, 2, 3; XML 1.0, XSLT 1.0, XPath 1.0 ; SOAP 1.1; JavaScript ECMA-262, revision 5; Media JavaScript API; C layer SDK | |
| DRM option: | Secure Media, Verimatrix (MAG255) |
| Middleware supported: | Stalker, Netup, SmartLabs, Netris, Beenius |
Interfaces
| Audio output S/PDIF HDMI 1.4-output Composite + stereo A/V output Ethernet 100 Mb/s USB 2.0 (WiFi-adapter can be connected) |
Sources of media content
| PC and NAS in local network, Stream media protocols (RTSP, RTP, UDP, IGMP, HTTP), USB-devices |
Audio&Video
| Audio сodecs: | MPEG-1 layer I/II, MPEG-2 layer II, MPEG-2 layer III (mp3), Dolby Digital (optional), DTS (optional) |
| Audio formats: | MP3, MPA, M4A, WMA (optional), Ogg, WAV |
| Video modes: | 1080i, 1080p, 720p, 576p, 480р, PAL, NTSC |
| Video сodecs: | MPEG1/2 MP@HL, H.264 HP@level 4.1, MPEG4 part 2 (ASP), WMV-9 (optional), VC1 video, XviD; HD video supporting (up to 40 Mbit/s and above) |
| Video containers: | MKV, MPEG-TS, MPEG-PS, M2TS, VOB, AVI, MOV, MP4, ASF, QT, WMV |
| Image formats: | JPEG, PNG, BMP, GIF, RAW |
| Subtitles: | DVB, SRT, text MKV |
| Playlist formats: | M3U |
Standard set
| MAG254/255 Set-Top Box, user manual, Mini jack cable to RCA (A/V), Power adapter 12V 1A, remote control, 2 AAA batteries, packaging |
RECEIVER
HDMI CABLE
REMOTE CONTROLL
SHORT MAMUAL (EN)
Production finished ! Replacement is MAG 322 / MAG 322w1
